WHOLE LOT OF ZEPPELIN
S TA G E R I D E R & T E C H N I C A L S P E C I F I C A T I O N
Band Contact: Robert Pickering Phone: (phone number hidden) Email: (email hidden)
1. AUDIO, VISUAL & TECHNICAL REQUIREMENTS
Tracks & IEM Click: Band provides an on-stage Soundcraft Ui24R digital mixer. A single Mono Backing Track feed is sent directly to
FOH via XLR. Internal Click Track (Right Channel) routes directly to band IEMs on stage (no FOH click feed required).
Visuals / Video Projection: Band will provide a custom **MP4 video file** on a **USB flash drive** for display on venue screen/
projector during the performance (featuring band logo and visuals). Venue to provide playback system and projector/display input
interface.
Direct Inputs (DI) & Rig Feeds:
Electric Guitar: Requires 2 balanced XLR feeds (Left & Right) directly from guitar floor processor/rig to FOH.
Bass Guitar: Requires 1 Direct Input (DI) / XLR line output from bass rig to FOH.
Vocal Setup:
Lead Vocal: Uses an on-stage vocal processor provided by the band. FOH receives an XLR output directly from processor.
Guitar Vocal & Bass Vocal: Standard vocal microphones (e.g., Shure SM58) on tall boom stands.
Stage Monitoring & Power:
Floor Wedges: Minimum 4 floor wedge monitors on separate mixes across the stage (Lead Vocal, Guitar/Vocal, Bass/Vocal,
Drummer).
Stage Power: Minimum 2 dedicated 20A AC power drops on stage (1 for backline amps/rigs, 1 for Ui24R/tracks rack).
2. INPUT LIST & STAGE CHANNEL MAP
CH INPUT / INSTRUMENT SOURCE / MICROPHONE STAND / HARDWARE / NOTES
1 Kick Drum Dynamic Mic (e.g., Beta 52) Short Boom Stand
2 Snare Drum Dynamic Mic (e.g., SM57) Short Boom Stand
3 Rack Tom 1 Dynamic / Clip Mic Rim Clip / Short Boom
4 Rack Tom 2 Dynamic / Clip Mic Rim Clip / Short Boom
5 Floor Tom Dynamic / Clip Mic Rim Clip / Short Boom
6 Hi-Hat Condenser Mic Small Boom Stand
7 Overhead Left Condenser Mic Tall Boom Stand
8 Overhead Right Condenser Mic Tall Boom Stand
9 Bass Guitar DI Box / XLR Line Out From Bass Rig
10 Guitar Left XLR Output (Balanced) Direct from Guitar Floor Processor
11 Guitar Right XLR Output (Balanced) Direct from Guitar Floor Processor
12 Lead Vocal XLR Line Output Direct from On-Stage Vocal Processor
13 Guitar Vocal Standard Vocal Mic (SM58) Tall Boom Stand
14 Bass Vocal Standard Vocal Mic (SM58) Tall Boom Stand
15 Backing Track XLR Line Output (Mono) Direct from Band Ui24R Digital Mixer
3. GREEN ROOM & DRESSING ROOM REQUIREMENTS
Dressing Room: Secure, clean, private green room / dressing room accessible prior to soundcheck through 30 minutes post-show.
Amenities: Access to clean restroom facilities, minimum 6 chairs, clean mirror, and adequate lighting.
Catering Note: No hospitality or catering buyouts required but appreciated.
•
•
•
◦
◦
•
◦
◦
•
◦
◦
•
•
